Build a Piano App using JavaScript

Subha Chanda
Subha Chanda
- December 27, 2022
Build a Piano App using JavaScript

In this tutorial, we will be building a piano using HTML, CSS, and JavaScript. This will be a great article to learn about some new stuff, like the HTML audio attribute and how we can use it in JavaScript. But, to start building this project, we’ve to know some basics like,

  • Basic HTML
  • Basic CSS including CSS Flexbox
  • Basic JavaScript

What will we learn in this tutorial?

  • The HTML audio tag
  • The Data attribute
  • The keydown Event Listener
  • Adding Classes using JavaScript

The HTML Part

First, let's see the output of the piano.

Piano Demo

Here is the live version of it. Try it before jumping into the article.

As you can see, the piano will have different black and white keys. The white keys represent the seven notes of a piano(A-B-C-D-E-F-G), and the black keys will represent the sharp or flat notes. Also, for the background, we'll be using linear gradients. Our HTML is very simple. We'll have an individual divs for every piano key. Our piano consists of 12 keys. So, we will add twelve div wrapped into a parent div. Each div will have a unique data attribute. The data attributes will be used to map the div with their audio. Also, our piano keys will have styles according to the key type. The black keys will have an extra class black, and the white keys will have an extra class white. Other than that, all the div for the keys will have a class called key. And, all the keys will be finally wrapped into a div called piano.

Here's our HTML

index.html
<!DOCTYPE html>
<html lang="en">

<head>
    <meta charset="UTF-8">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <title>Piano</title>
</head>

<body>
    <div class="piano">
        <div class="key white" data-note="C"></div>
        <div class="key black" data-note="Cs"></div>
        <div class="key white" data-note="D"></div>
        <div class="key black" data-note="Ds"></div>
        <div class="key white" data-note="E"></div>
        <div class="key white" data-note="F"></div>
        <div class="key black" data-note="Fs"></div>
        <div class="key white" data-note="G"></div>
        <div class="key black" data-note="Gs"></div>
        <div class="key white" data-note="A"></div>
        <div class="key black" data-note="As"></div>
        <div class="key white" data-note="B"></div>
    </div>
</body>
</html>

The data Attribute in JavaScript

The data attribute in HTML5 helps us to store some extra information without any extra work. Any attribute, whose attribute name starts with data- is a data attribute. So, for our piano, we are storing some extra data called note with the help of the data attribute in each of the div. For example, in the first div the data-note="C" stores a piece of information that this key will represent the C note in our piano. The data attributes can be easily targeted in JavaScript using the dataset keyword. We will discuss it more later in this article. To know more about the data attribute, visit the link here.

Styling the Piano

The first step of styling an HTML page is to reset the default styles. Here also, we are resetting the margin and padding by targeting the global selector. We are also adding box-sizing: border-box because it'll help us to work with flexbox easily.

styles.css
* {
    margin: 0;
    padding: 0;
    box-sizing: border-box;
}

For the background, we'll add a linear gradient. To speed up the process, I've used an online gradient generator called CSS Gradient. Here's our body.

styles.css
body {
    background: #0f2027;
    /* fallback for old browsers */
    background: -webkit-linear-gradient(to bottom, #2c5364, #203a43, #0f2027);
    /* Chrome 10-25, Safari 5.1-6 */
    background: linear-gradient(to bottom, #2c5364, #203a43, #0f2027);
    /* W3C, IE 10+/ Edge, Firefox 16+, Chrome 26+, Opera 12+, Safari 7+ */
}

Now, comes the tough part, styling the keys of the piano. First of all, let's add a height and a width for the piano. Because we'll be using flexbox, our flexbox will also be invoked here.

styles.css
.piano {
    height: 100vh;
    width: 100%;
    display: flex;
    justify-content: center;
}

Styling the White Keys

The first thing to style the keys is to give them a height and a width. Otherwise, our keys will not be visible at all. We'll also need a border for each element to separate one from the other.

styles.css
.white {
    width: 9%;
    min-width: 60px;
    height: 70%;
    background-color: white;
    border: 1px solid #ccc;
}

We are giving the white keys a width of 9% of the parent and a height of 70% of the parent. We are also adding a min-height property so that our keys don't become too small. Our white keys will have a background color of white and a solid border of 1px. The border color will be #CCCCCC, which is a darker shade of white. Here's the output of our piano until now,

Keys of Piano

Styling the Black Keys

The styling of the black keys is very similar to the white keys. The main difference is that the height of the black keys is smaller than the white keys.

styles.css
.black {
    width: 8%;
    height: 45%;
    background-color: black;
}

We are giving it a width of 8% of the parent, a height of 45% of the parent and background color of black.

Here's the output after adding the black keys,

Black and White Keys of Piano

This doesn't look like the one we want. How do we bring the black keys on top of the white ones? The easiest idea is to add some negative margins. Because our black keys have a width of 8%, we need to distribute it equally on two white keys. For that, we’ll add a -4% of left margin and a -4% of the right margin. We’ll also need to add a z-index to bring it forward. So, our complete style for the black keys will look like this,

styles.css
.black {
    width: 8%;
    height: 45%;
    margin-left: -4%;
    margin-right: -4%;
    z-index: 2;
    background-color: black;
}

Now our piano will look similar to the one we wanted.

The Audio Tag

We have not added one important portion in our HTML document till now. We need to add audio tags for each key into the HTML element.

The HTML audio tag is used to embed sound into webpages. The src attribute into the audio tag will represent the source of the audio. In the Github repo of this project, you will see that we have a folder called notes, inside the notes folder, we have all the mp3 sounds of the individual keys that we are going to use for this tutorial. Our audio src attribute will refer to the location of these sources. Each of the audio tag will also have a unique ID to determine the individual keys. Here's the remaining HTML part:

index.html
<audio src="./notes/C4.mp3" id="C"></audio>
<audio src="./notes/Cs4.mp3" id="Cs"></audio>
<audio src="./notes/D4.mp3" id="D"></audio>
<audio src="./notes/Ds4.mp3" id="Ds"></audio>
<audio src="./notes/E4.mp3" id="E"></audio>
<audio src="./notes/F4.mp3" id="F"></audio>
<audio src="./notes/Fs4.mp3" id="Fs"></audio>
<audio src="./notes/G4.mp3" id="G"></audio>
<audio src="./notes/Gs4.mp3" id="Gs"></audio>
<audio src="./notes/A4.mp3" id="A"></audio>
<audio src="./notes/As4.mp3" id="As"></audio>
<audio src="./notes/B4.mp3" id="B"></audio>

Our notes folder has more notes. But for this tutorial, we are only using standard piano keys(C4 to B4).

Putting the Parts together with JavaScript

Now comes the most important part - JavaScript. We'll start by selecting few elements of the DOM. These elements will be used to manipulate our piano. First of all, we'll need to select all the keys that are available to us. All the keys have a class of key, so targeting the key class will do the job.

const keys = document.querySelectorAll('.key');
We would also need to target the regulars and the sharp keys. As you know, our regulars have a white class and the sharps have a black class. Let's target them now.
const regulars = document.querySelectorAll('.key.white');
const sharps = document.querySelectorAll('.key.black');
Now that we have selected the elements, the next thing we will do is to add a function to each of the keys.
keys.forEach((key) => {
  key.addEventListener('click', () => playNote(key));
});

Here, we are binding a function with the click event. For each click, the playNote function will be executed. The playNote function takes a single parameter ‘key’, which is the audio of that key. We are using arrow functions here.
Let's move to write the playNote function.
Our function takes a single parameter and that is the key that is pressed. The first thing when writing our function is to identify which key is pressed. How do we do so? Here comes the data attribute in use. At the playNote function call, we are passing the keyparameter. The key parameter is nothing but the divwhich is clicked. So, to start with our function, let's first select the note that is pressed.
let playNote = (key) => {
  const noteSound = document.getElementById(key.dataset.note);
  console.log(noteSound);
};
To access the data attribute, we use the dataset keyword in JavaScript. If we console log the noteSound constant, we will see that it is returning the audio attribute depending on the key that is pressed. Our piano maps the audio id with the data-note attribute of the key to play the correct audio. To play the audio now, we'll use the play method.
let playNote = (key) => {
  const noteSound = document.getElementById(key.dataset.note);
  noteSound.play();
};

Our piano is almost ready. But we can add a few modifications. If you press single key multiple times now, it’ll not play until the audio sound ends completely. We don't want it. We want to play the audio every time the key is clicked. To do so, we have to set the current time to zero each time the key is clicked. Another modification we can do here is to add a class to make it visible which key is pressed. For that, we have to add two classes to our CSS file. One is to show the active white key and another one is to show the active black key. We will just change the background color of the keys.
.white.active {
    background-color: #ccc;
}

.black.active {
    background-color: #333;
}

As you can see, the .white.active class has a darker white background and the .black.active class has lighter black color. To add the colors when keys are pressed, we'll use the classList.add method available in JavaScript
let playNote = (key) => {
  const noteSound = document.getElementById(key.dataset.note);
  noteSound.currentTime = 0;
  noteSound.play();
  key.classList.add('active');
  noteSound.addEventListener('ended', () => {
    key.classList.remove('active');
  });
};

We are adding the class using the key.classList.add('active') method to a key whenever the key is pressed. And we are removing the class when the audio is completely played. For this, we are listening to an event called ‘ended’ and whenever this event is triggered, we are removing the class using key.classList.remove(‘active’) method.
And we are done building the piano.
Building the Piano Computer Keyboard Friendly
But, we can stretch our piano further. How about playing our piano using the keyboard? Sounds awesome right? Let's just jump into building it our computer keyboard friendly!
First of all, we have to choose which keys to use. I think the middle layer of the keyboard, i.e., the line of keys with the Caps Lock button is perfect for it, because it has keys in the middle of it above it, just like an original piano. So, we can use the keys from A to J for the regular keys, and keys from W to Y for the sharps.
We will start by adding some CSS to help our users understand which key to press. Inside all the divs, we will add the corresponding keyboard key. So, now our HTML of divs will look like this now,
<div class="piano">
    <div class="key white" data-note="C">A</div>
    <div class="key black" data-note="Cs">W</div>
    <div class="key white" data-note="D">S</div>
    <div class="key black" data-note="Ds">E</div>
    <div class="key white" data-note="E">D</div>
    <div class="key white" data-note="F">F</div>
    <div class="key black" data-note="Fs">R</div>
    <div class="key white" data-note="G">G</div>
    <div class="key black" data-note="Gs">T</div>
    <div class="key white" data-note="A">H</div>
    <div class="key black" data-note="As">Y</div>
    <div class="key white" data-note="B">J</div>
</div>

In the CSS part, we will style the ‘key’ class. The color of the text will be updated in the white and black classes because the colors will be different for the key types. We will use flexbox to position the text. Here’s our complete styling,
* {
  margin: 0;
  padding: 0;
  box-sizing: border-box;
}

body {
  background: #0f2027;
  /* fallback for old browsers */
  background: -webkit-linear-gradient(to bottom, #2c5364, #203a43, #0f2027);
  /* Chrome 10-25, Safari 5.1-6 */
  background: linear-gradient(to bottom, #2c5364, #203a43, #0f2027);
  /* W3C, IE 10+/ Edge, Firefox 16+, Chrome 26+, Opera 12+, Safari 7+ */
}

.piano {
  height: 100vh;
  width: 100%;
  display: flex;
  justify-content: center;
}

.key {
  display: flex;
  justify-content: center;
  align-items: flex-end;
  font-size: 1.2rem;
  font-weight: bold;
  padding-bottom: 20px;
}

.white {
  width: 9%;
  min-width: 60px;
  height: 70%;
  background-color: white;
  border: 1px solid #ccc;
  color: #000;
}

.black {
  width: 8%;
  height: 45%;
  margin-left: -4%;
  margin-right: -4%;
  z-index: 2;
  background-color: black;
  color: #fff;
}

.white.active {
  background-color: #ccc;
}

.black.active {
  background-color: #333;
}

Now, let’s jump back to JavaScript again. We will create two arrays. These arrays will represent the keys. Check the arrays below, and you’ll get an idea.
const whites = ['a', 's', 'd', 'f', 'g', 'h', 'j'];
const blacks = ['w', 'e', 'r', 't', 'y'];

The regular keys will be accessed through the keys a to j, and the sharps will be accessed through the keys w to y.
Now comes the most important section, the logic part. When a key is pressed, a keydown event is triggered. We will use this event to play audio.
document.addEventListener('keydown', (e) => {
  if (e.repeat) return;
  const key = e.key;
  const whiteKeyIndex = whites.indexOf(key);
  const blackKeyIndex = blacks.indexOf(key);

  if (whiteKeyIndex > -1) playNote(regulars[whiteKeyIndex]);
  if (blackKeyIndex > -1) playNote(sharps[blackKeyIndex]);
});

We are adding an event listener to listen to the keydown event. When the event is observed, we pass in a parameter inside the event listener function. To get the key that is pressed, we will use the e.key method. The e.key method will return the key that is pressed. Now, we’ll get the index of the key and will store it inside a variable. To store the white key index, we are using a variable called whiteKeyIndex and for the black key index, we’ll use a blackKeyIndex variable. To get the index, we’ll use theindexOfmethod. Inside the array of whites or blacks, we are checking the index of the key that is pressed using the indexOfmethod. Now that we know the index of the key that is pressed, we will write a condition. The condition is, if a white key is found(-1 means not found, any value larger than it means that the key is found), the playNotefunction will be invoked. And, inside the playNote function, we’ll pass in the key by locating it in the array with regulars[whiteKeyIndex]. We are doing the same step for the black keys also. Please keep in mind, because we are using the array to locate the key, our array should be in the exact order in which we want our piano keys to be set up.
The only thing that is left in our code is that, if you hold a key, the audio will sound ridiculous. Because, when a key is held, the keydownevent gets triggered after every few seconds. To stop this behavior, we’ll check if the key is held down. If it is, then we’ll simply return the function. Returning the function will not execute any code. And this is done by if (e.repeat) return line. And we are done. Our piano is ready.
To check the complete source code, visit the GitHub repo here.
Conclusion
I hope you enjoyed building this piano. To get such more tutorials, keep visiting nemo.hashnode.dev. Here is another simple JavaScript tutorial about building a covid 19 tracker.
